70527-363*

* Plated Spec On Contact Area
1: Gold Flash
2: Gold Plated 0.127 Micrometers / 5 Microinch
3: Gold Plated 0.254 Micrometers / 10 Microinch
4: Gold Plated 0.381 Micrometers / 15 Microinch
5: Gold Plated 0.762 Micrometers/ 30 Microinch
7: Bright Tin Plated 2.54 Micrometers / 100 Microinch Min. Overall
8: Matte Tin Plated 2.54 Micrometers / 100 Microinch Min. Overall
產品詢問
產品規格
Pitch 1.0mm
Circuits 36
Current Per Circuit 1A
Ratting Voltage 50V
Contact Resistance 20mΩ
Durability 50 times
Service Temperature -25℃~85℃
Mating Series 70525/70526 Series
Mounting Type Vertical SMT, W/ Fitting Nail
Enhanced Polarized No
Housing or terminal Material Thermoplastic
Color Black
Dip Pin Length -
技術文件
3D File 會員登入
2D File
Specification
Package Spec

更多資訊

  1. The values specified in this website are only for reference.
    The products/specifications are subject to change without notice.
  2. We strongly suggest you to contact our sales for further information when considering use of any of the products in any other way than the recommended applications or for a specific use that requires an extremely high reliability.
