70094-227*

* Contact Area Plating Spec:
1=Gold Flash
2=Gold Plated 0.127 Micrometer/5 Microinch
3=Gold Plated 0.254 Micrometer/10 Microinch
4=Gold Plated 0.381 Micrometer/15 Microinch
5=Gold Plated 0.762 Micrometer/30 Microinch
7=Bright Tin Plated 2.54 Micrometer/ 100 Microinch Min Over All
8=Matte Tin Plated 2.54 Micrometer/ 100 Microinch Min Over All

Hỏi đáp sản phẩm

thông số kỹ thuật sản phẩm
Pitch	3.0mm
Circuit	22
Current Rating	8A
Rating Voltage	600V
Mounting Type	Vertical Dip
Contact Resistance	5 mΩ
Color	Black
Durability	30 times
Wire AWG	-
Operating Temperature	-40℃~105℃
Enhanced Polarized	Yes
Housing Material	LCP

Tài liệu kỹ thuật

3D File	Đăng nhập thành viên
2D File
Specification
Package Spec

Thêm thông tin

The values specified in this website are only for reference.
The products/specifications are subject to change without notice.
We strongly suggest you to contact our sales for further information when considering use of any of the products in any other way than the recommended applications or for a specific use that requires an extremely high reliability.
